Electrical Specifications

• Input Voltage

  90~240Vac

• Output Voltage

  11~16.8V 5-120A (adjustable), up to 1700W

• Charging Mode

  Supply, Lead-Acid, LiFePO4, Custom, NORM, AGM

Paratemers

• Input

  AWG18#, 2m (Note: The US version comes with two AC power cables. )

• Output Voltage

  Positive AWG4#, 2.2m or 5m Negative AWG4#, 2.2m or 5m

• Working Temperature

  14°F to 104°F (-10°C to 40°C)

• Storage Temperatue

  -4°F to 167°F (-20°C to 75°C)

• Note

  To switch the output line length, please change the settings in Output Line Settings.

Safety

• Protection

  Over-temperature protection, input low voltage protection, overload protection, bad battery protection, short circuit protection, overvoltage protection, reverse connection protection, host abnormality protection.
