Tool Description
TOPDON ArtiPad I serves as a complete diagnostic solution for comprehensive automotive problems, with all necessary functionalities such as ECU online programming & coding, active tests, 11 most commonly-used service functions, etc. placing this pro-level scanner in a class of its own.
Technical Specifications

Operating System: Android 5.1
Processor: 8-core 2.0GHz processor
Memory: 2GB RAM
Hard Disk: 64GB Embedded Memory (expandable to 128 GB via TF card)
Display: 12"touch screen, 1920x1200 dpi
Connectivity: USB 2.0, Bluetooth 2.0, Ethernet/Wi-Fi (802.11b/g/n)
Connection: 2.0 USB, HDMI 1.4a, SD Card (Support up to 32GB)
Camera: Rear: 8.0 Megapixel, Autofocus with Flashlight; Front: 2.0 Megapixel
Sensors: Gravity Accelerometer
Audio Input/output: Microphone, Speakers, 3.5 mm stereo headset jack
Battery: 15000mAH Lithium-polymer battery
Input Voltage: DC/5V/3A
Power Consumption: Max 20W
Operating Temperature: -10°C~55°C (14°F~131°F)
Dimensions: 70mm*42.5mm*20mm
Weight: 2.1kg (4.63 lb)

Package List

1* ArtiPad I Tablet

1* VCI connector

1* OBD II Extension Cable

1* OBDI Adaptor

1* Cigarette Lighter Cable

1* Battery Clamps Cable

1* Power Adaptors

1* USB Cable

1* Password Envelope

1* Non-16pin Adaptor Cable Kit

(Adaptors of AUDI-4 BENZ-14 BENZ-38 BMW-20 CHRYSLER-6 DAEWOO-12 DAIHATSU-4 FIAT-3 FORD-6+1 GEELY-22 GM/VAZ-12 HONDA-3 KIA-20 MAZDA-17 MITSUBISHI/HYUNDAI-12+16 NISSAN-14+16 SSANGYONG-14 SSANGYONG-20 SUBARU-9 SUZUKI-3 TOYOTA-17 TOYOTA-22 UNIVERSAL-3)

Features

  • Intelligent automotive diagnostic tablets designed for mid-scale or large-scale workshops and vehicle repairing houses.

  • Extensive coverage for over 80 makes and models worldwide.

  • Cloud-based ECU Programming for BMW, BENZ, VW/AUDI/SKODA/SEAT, PORSCHE,LAND ROVER/JAGUAR,SUBARU, and NISSAN, without the need of the manufacture software.

  • Online ECU Coding for software modifications to a vehicle.

  • Supports Active Test, Module Replacement, Modification, Personalization, Anti-theft & Key Matching, and more (varies by the vehicle manufacturer, year, and model).

  • Access to all systems and subsystems.

  • Supports 11 Service Functions.

  • Multilingual menu support (23).

  • Advanced configuration.

  • VCI Bluetooth wireless Diagnosis.

  • Instant remote technical support.

  • User-friendly and ergonomic designs.
